Product Detail

Factory Wholesale 5kWh Lithium Battery Pack 48V 100Ah Lifepo4 Batteries Power Wall 5kWh 10kWh 30kWh Battery Bank Power Supply

No price
Nominal Voltage
  1. 48v
  2. 51.2v
Battery Type
  1. pack
  2. prismatic
Nominal Capacity
  1. 100Ah
Collect
  • 商品说明

Product Description

Product Name
Home Energy Storage Battery Pack 48V 100Ah Lifepo4 Battery power bank
Cell
Capacity
100Ah
Nominal Voltage
3.2 V
Dimension
49.9x 160x 118.5mm
Weight
2 kg
Battery Pack
Parameters
Combination Method
16S1P
Capacity
Nominal Capacity： 100Ah

Voltage
Nominal Voltage： 51.2V
Cut-off Voltage： 44.8V~ 57.6V

Charge
Standard Charge：0.5C(50A)
Quick Charge： 1C(100A)
Discharge
Discharge Current： 100A
Weight
48± 1Kg
(L×W × H)
Dimension

540mm*495mm*177mm

Operating Temperature
Charge ： 0℃ ~45℃；
Discharge： -20℃ ~60℃；

Protection function
Single over-voltage/under-voltage, charging/discharging over-current, short circuit, temperature

Cycle life
(0 . 2C, 25℃@80% DOD)) ＞4000 times

Protection level
IP20


Parallel options
Communication type
CAN、RS485、 RS232
Parallel Quantity
16 groups (series connection not supported)

Company Introduction

Certifications

Buyer's Real Reviews

Packing & Delivery
